| Frequency range |
| N9040B-508 |
頻率范圍，3 Hz 至 8.4 GHz
- 3 Hz 至 8.4 GHz
- 3.6 或 8.4 GHz 可選內置前置放大器
- 可作為售后升級選件
|
| N9040B-513 |
頻率范圍，3 Hz 至 13.6 GHz
- 3 Hz 至 13.6 GHz
- 3.6 或 13.6 GHz 可選內置前置放大器
- 可作為售后升級選件
|
| N9040B-526 |
頻率范圍，3 Hz 至 26.5 GHz
- 3 Hz 至 26.5 GHz
- 3.6 或 26.5 GHz 可選內置前置放大器
- 可作為售后升級選件
|
| N9040B-550 |
Frequency Range 3 Hz To 50 GHz
- Frequency Range: 3 Hz to 50 GHz
- Available at time of purchase only
|
| N9040B-544 |
Frequency Range 3 Hz To 44 GHz
- Frequency Range: 3 Hz to 44 GHz
- Available at time of purchase only
|
| |
| Connector options |
| N9040B-ALV |
輔助對數視頻輸出
- 輸出變化大約 25 mV/dB
- 屏幕上方的輸出為 1.6 V
- 輸出阻抗為 50 Ω（標稱值）
- 可作為售后升級選件
|
| N9040B-C35 |
連接器，射頻輸入，3.5 mm 陽頭
- 使用 3.5 mm 連接器代替標配的 N 型連接器
- 可作為售后升級選件
|
| N9040B-CRP |
連接器，可編程后面板中頻輸出
- 中頻輸出的頻率可以在 10 MHz 至 75 MHz 之間以 500 kHz 步進進行調整
- 中頻輸出帶寬為 100 MHz 標稱值，中心頻率為 70 MHz
- 連接器類型：SMA（陰頭），50 Ω 阻抗標稱值
- 可作為售后升級選件
|
| N9040B-YAV |
Y 軸輸出
- 屏幕視頻輸出與顯示視頻相同
- 模擬輸出連接器的對數視頻滿標度為 1 V
- 模擬輸出的線性視頻采用線性標度
- 可作為售后升級選件
|
| |
| Preamplifier |
| N9040B-P08 |
前置放大器，8.4 GHz
- +35 dB 增益
- -172 dBm DANL，配有前置放大器和本底噪聲擴展
- 前置放大器能夠增強探測低電平信號的能力
- 可作為售后升級選件
|
| N9040B-P13 |
前置放大器，13.6 GHz
- +35 dB 增益
- -170 dBm DANL，配有前置放大器和本底噪聲擴展
- 前置放大器能夠增強探測低電平信號的能力
- 可作為售后升級選件
|
| N9040B-P26 |
前置放大器，26.5 GHz
- +35 dB 增益
- -162 dBm DANL，配有前置放大器和本底噪聲擴展
- 前置放大器能夠增強探測低電平信號的能力
- 可作為售后升級選件
|
| N9040B-P44 |
Preamplifier, 44 GHz
- +40 dB gain up to 44 GHz for enhanced sensitivity to low signal levels
- Up to –172 dBm DANL with preamp and noise floor extension
- Available as a post-purchase upgrade
|
| N9040B-P50 |
Preamplifier, 50 GHz
- +40 dB gain up to 50 GHz for enhanced sensitivity to low signal levels
- Up to –172 dBm DANL with preamp and noise floor extension
- Available as a post-purchase upgrade
|
| |
| Bandwidth |
| N9040B-B2X |
Analysis Bandwidth, 255 MHz
- Supports real-time spectrum analyzer
- Capture memory: 2 GB
- ADC resolution: 14 bits
- Available as a post-purchase upgrade
|
| N9040B-B5X |
Analysis Bandwidth, 510 MHz
- Supports real-time spectrum analyzer
- Capture memory: 2 GB
- ADC resolution: 14 bits
- Available as a post-purchase upgrade
|
| N9040B-B25 |
分析帶寬，25 MHz
- 捕獲存儲器：2 GB
- ADC 分辨率：12 位元
- 可作為售后升級選件
|
| N9040B-B40 |
Analysis Bandwidth, 40 MHz
- Capture memory: 2 GB
- ADC resolution: 12 bits
- Available as a post-purchase upgrade
|
| N9040B-H1G |
1 GHz 分析帶寬
- 分析帶寬擴展至 1 GHz
- ??頻率范圍：3 Hz 至 50 GHz
- ??ADC 分辨率：12 位
- ??包括 255 MHz（B2X）能力
- ??只在購買時提供
|
| |
| Performance options |
| N9040B-EA3 |
電子衰減器，3.6 GHz
- 步長：1 dB
- 范圍：0 至 24 dB
- 包括機械衰減的完整范圍：94 dB
- 可作為售后升級選件
|
| N9040B-EMC |
基本預兼容性 EMI
- 完全符合 CISPR 16-1-1（2010）標準的檢波器
- 高達 18 GHz 的 CISPR 頻段預置
- 使用 3 臺檢波器在游標處測量
- 用于信號識別的調諧和偵聽
- 可作為售后升級選件
|
| N9040B-FP2 |
快速功率，帶寬高達 40 MHz
- 單次采集帶寬：40 MHz
- 啟用硬件加速快速功率測量
- 為功率測量而優化
- 可作為售后升級選件
|
| N9040B-RTS |
Real-Time Wideband I/Q Data Streaming
- Real-Time Wideband I/Q Data Streaming
- May be combined with X-COM IQC5255B for turnkey 255 MHz record and playback solution
- 16-bit I + jQ digital data at up to 300 MSamples/S, continuously variable based on span setting
- Available as a post-purchase upgrade
|
| N9040B-FT1 |
Frequency Mask Trigger, Basic Detection License
- Capture elusive, intermittent signals for further analysis
- > 15 µs signal duration
- Seamless operation in 89600 VSA Software and N9067C pulse application
- Available as a post-purchase upgrade
|
| N9040B-FT2 |
Frequency Mask Trigger, Optimum Detection License
- Capture elusive, intermittent signals for further analysis
- > 3.6 µs signal duration
- Seamless operation in 89600 VSA Software and N9067C pulse application
- Available as a post-purchase upgrade
|
| N9040B-DUA |
Duplex IF RTSA
- Enables control of 2 x 255MHz DIF for optimized frequency and time domain analysis in RTSA mode at the same center frequency
- Able to view RT spectrum, Power vs Time, Powergram, and Spectrogram all at the same time with independent time domain and frequency domain spans
- Requires option B5X and RT1 or RT2
- Available as a post-purchase upgrade
|
| N9040B-TDS |
Time Domain Scan
- ~90% overlap in the time domain for amplitude accuracy and fast transient capture
- CISPR-compliant amplitude accuracy and weighted detector performance
- Monitor spectrum and amplitude probability distribution
- Available as a post-purchase upgrade
|
| |
| Calibration options |
| N9040B-A6J |
ANSI Z540 一致性校準
- 從工廠裝運并經過 ANSI Z540 校準
- 提供測量結果、不確定度數據和技術指標
- 確定合格/不合格狀態時不包含不確定度數據
- 只在購買時提供
|
| N9040B-UK6 |
包含測試數據的商業校準證書
- 由是德科技工廠實施的商業校準
- 校準證書印刷本
- 關于從 Infoline 下載測試數據報告的指導
- 只在購買時提供
|
| |
| |
| Real time signal analysis |
| N9040B-RT1 |
Real-time analysis, basic detection, 255 MHz with B2X/H1G, 500 MHz with B5X, license |
| N9040B-RT2 |
Real-time analysis, optimum detection, 255 MHz with B2X/H1G, 500 MHz with B5X, license |
| |
| Security features |
| N9040B-SF1 |
安全特性，不包括啟動程序
- 許可證密鑰激活，提供額外的安全功能特性
- 需要 A.12.06 版本或更高版本的軟件
- 可作為售后升級選件
|
| N9040B-SF2 |
安全特性，禁止保存結果
- 許可證密鑰激活，提供額外的安全功能特性
- 需要 A.14.00 版本或更高版本的軟件
- 可作為售后升級選件
|
| N9040B-SSD |
額外的可拆卸固態硬盤
- 串行 ATA（SATA）數據接口的可拆卸固態硬盤
- 堅固的可拆卸托架，少可插入 1500 次
- 操作系統、軟件和校準文件鏡像
- 可作為售后升級選件
|
| |
| |
| N9040B-ESC |
External source control |
| |
| N9040B-DVR |
USB DVD-ROM/CD-R/RW 驅動器
- 連接到前面板或后面板上的 USB 端口
- 從 Microsoft® Windows 用戶界面訪問 DVD 或 CD 介質
- 可作為售后升級選件
|
| |
| N9040B-KB2 |
USB keyboard Smaller keyboard |
| |
| N9040B-MLP |
50 至 75 Ω 小損耗衰減器（N 型至 BNC）
- 連接器：50 Ω N 型（陽頭）至 75 Ω BNC（陰頭）連接器
- 插入損耗：5.7 dB
- 輸入/輸出回波損耗：20 dB
- 大輸入功率：1 W
- 平坦度：+/- 2 dB
- 可作為售后升級選件
|
| |
| N9040B-MSE |
Mouse, USB |
| |
| N9040B-2CM |
Rack mount flange kit 265.9mm H (6U) - two flange brackets, two standard rails, DARK COLORS |
| |
| N9040B-2CP |
Rack mount flange and handle kit 265.9mm H (6U) - two brackets, handles, rails, DARK COLORS |
| |
| Application software |
| 89601B |
- 89600 VSA 軟件
- 蜂窩、無線連通性、航空航天、國防、通用
- 同時查看多個時域、頻域和調制域視圖
- 先進故障診斷工具包括觸發、記錄和回放
- 支持超過 45 種是德科技測量平臺
|
| N6171A |
MATLAB 軟件
- 創建任意波形
- 定制測量/數據分析例程、儀器應用程序/測試系統
- 自動化測量以及信號與報告生成
- 可通過購買兼容儀器從是德科技直接獲
|
| N9063C |
配有多點觸控用戶界面、適用于 UXA 的模擬解調測量應用軟件
- 多點觸控用戶界面
- 對 AM、FM、PM 和 FM 立體聲信號進行一鍵式測量
- 顯示調制參數：AM 深度、FM/PM 偏差、THD、SINAD、FM 立體聲
- 可作為售后升級選件
|
| N9067C |
Pulse Measurement Application, Multi-touch UI
- Automatically synchronize to pulsed signals up to 50 GHz and bandwidth of 510 MHz
- View key pulse signal modulation performance indicators and pulses in a time, frequency and phase-domains
- Runs inside X-Series signal analyzers with multi-touch UI
查看詳情
|
| N9068C |
Phase Noise Measurement Application, Multi-touch UI
- 1-touch measurements for analyzing phase noise in frequency domain (log plot) & time domain (spot frequency)
查看詳情
|
| N9069C |
噪聲系數測量應用軟件，多點觸控用戶界面
- 噪聲系數/增益測量
- 一鍵式測量：噪聲系數、增益、Y 因數、有效溫度和熱態/冷態功率密度
- 支持 SNS 346 系列噪聲源和 U7227x 系列 USB 前置放大器
- 可作為售后升級選件
查看詳情
|
| N9071C |
GSM / EDGE / Evo Measurement Application, Multi-Touch UI
- GSM, EDGE and EDGE Evolution including VAMOS1 and Multi-Carrier BTS (MCBTS) per 3GPP GERAN standard
- Base station and mobile station RF transmitter measurements; analog baseband measurements One-button measurements with pass/fail per the standard
|
| N9073C |
W-CDMA/HSPA/HSPA+ Measurement Application, Multi-touch UI
- W-CDMA/HSPA/HSPA+ per 3GPP Release 99 to 8
- Includes uplink/downlink RF transmitter measurements
- Transmit analog baseband measurements with BBIQ hardware
- 1-touch measurements with pass/fail per the standard
|
| N9077C |
WLAN 802.11a/b/g/j/p/n/ac/af/ah/ax Measurement Application, Multi-Touch UI
- Compliant to 802.11a/b/g/j/p/n, 802.11ac, 802.11af, 802.11ah, 802.11ax IEEE series standards for WLAN design/manufacturing test
- Manual settings for 802.11a-turbo mode
- One-button pass/fail measurements per standard
|
| N9080C |
LTE/LTE-Advanced FDD 測量應用軟件，多點觸控用戶界面
- 按照 3GPP 第 8 版到第 13 版標準進行 LTE 和 LTE-Advanced FDD 信號分析
- 使用單一選件提供上行鏈路和下行鏈路測量
- 多達 5 個子載波的載波聚合
- 在具有多點觸控用戶界面的 UXA、PXA、MXA、EXA 和 CXA X 系列信號分析儀中運行
|
| N9081C |
Bluetooth Measurement Application, Multi-Touch UI
- Compliant with Bluetooth® Core Specification Version 2.1+ EDR & Low Energy (BR/EDR/LE 4.0/4.2/5.0)
- One-button measurements with pass/fail per the standard
|
| N9082C |
LTE / LTE-Advanced TDD Measurement Application, Multi-touch UI
- LTE and LTE-Advanced TDD per 3GPP Release 8 to 12
- Includes Uplink and downlink measurements in a single option
- Carrier aggregation up to five component carriers
- Runs inside UXA, PXA, MXA, EXA and CXA X-Series signal analyzers with multi-touch UI
|
| N9084C |
Short Range Communications Measurement Application, Multi-Touch UI
- Compliant with ZigBee (IEEE 802.15.4) and Z-Wave RF transmitter tests
- One-button measurements with pass/fail per the standard
- Runs inside UXA, PXA, MXA, EXA, and CXA X-Series signal analyzers with multi-touch UI
|
| N6141C |
EMI Measurement Application, Multi-Touch UI
- Built-in CISPR and MIL-STD compliant bandwidths, detectors and band presets
- Automated testing to regulatory Limit Lines with user-selected margins
- Amplitude correction for antennas, LISNs, cables, preamps
|
| N9054C |
VMA 矢量調制分析應用軟件，多點觸控用戶界面
- 用于猝發分析的 FFT 頻譜分析和時域分析工具
- 通用模擬和數字調制分析（可選）
- 在具有多點觸控用戶界面的 UXA、PXA、MXA、EXA 和 CXA X 系列信號分析儀中運行
|
| N9061C |
Remote Language Compatibility Application, Multi-Touch UI
- Emulate HP/Keysight 856xE/EC or 8566/8568 spectrum analyzers in remotely controlled, ATE systems
- Migrate 856xE/EC-based or 8566/8568-based ATE systems to seamlessly include a modern signal analyzer
|
| |
| Additional documentation |
| N9040B-AB1 |
Korean localization, user interface and getting started guide |
| N9040B-AB2 |
Chinese localization, user interface and getting started guide |
| N9040B-ABF |
French localization, user interface and getting started guide |
| N9040B-ABJ |
Japanese localization, user interface and getting started guide |
| N9040B-AKT |
Russian localization, user interface and getting started guide |
| N9040B-ABE |
Spanish localization, user interface and getting started guide |
| |
| N9040B-RTR |
Real-time Spectrum Recorder and Analyzer Application Example, License |
